General Purpose Solenoid Valve – 3/2 Normally Closed
0,00 USD
(0) Yorum | Comment
Stock code
CFMNR367
Mekanik Markt olarak 7/24 yanınızdayız. Bizimle Whatsapp ile iletişime geçerek ürünlerimiz hakkında detaylı bilgileri alabilirsiniz.
- EXPLANATION
General Purpose Solenoid Valve – Normally Closed
GASKET: NBR
HOUSING: STAINLESS
BODY: BRASS
CORE: STAINLESS
TEMPERATURE: -10 / +90 °C
General Purpose Solenoid Valves are two or three-way valves that operate with AC and DC electrical energy and provide control of various fluids (air, gas, fuel, steam, water, etc.). They consist of body, barrel, coil, diaphragm and core.
Solenoid valves are normally closed (when the coil receives energy, it opens the closed valve) and
It is manufactured in two types: normally open (to close the valve that is open when it receives energy from the coil)
is being done.
THINGS TO CONSIDER WHEN SELECTING A SOLENOID VALVE:
-The coil should be selected according to the operating voltage where it will be used (AC-DC). Protection and insulation should be made according to the place of application.
(It opens when the electricity comes out and returns to the closed position when you cut off the electricity.)
-Minimum and maximum pressure values in the line or system you will use are very important in selecting the valve.
-The quality and temperature of the fluid are direct factors in the selection of the valve.
-Pay attention to the installation and ensure that the direction of the fluid is in the same direction as the arrow mark on the body.
-Since the solenoid valve does not function as a check valve, fluid flows back in case of reverse pressure. In these cases, the solenoid valve
then installing a check valve is correct in terms of connection.
-The line where the valve is installed must be cleared of dirt.
-The coil should be selected according to the operating voltage where it will be used (AC-DC). Protection and insulation should be made according to the place of application.
(It opens when the electricity comes out and returns to the closed position when you cut off the electricity.)
-Minimum and maximum pressure values in the line or system you will use are very important in selecting the valve.
-The quality and temperature of the fluid are direct factors in the selection of the valve.
-Pay attention to the installation and ensure that the direction of the fluid is in the same direction as the arrow mark on the body.
-Since the solenoid valve does not function as a check valve, fluid flows back in case of reverse pressure. In these cases, the solenoid valve
then installing a check valve is correct in terms of connection.
-The line where the valve is installed must be cleared of dirt.
TECHNICAL SPECIFICATIONS
